Description

Voltage：48V

Rated Output：650W

Max Power (electric motor)：1200W

Max Torque (electric motor)：6.4N.m

Gear Ratio：72:13

Battery：48V24Ah

Battery Capacity：1152Wh

Charging Time (SOC 10%-80%）：4 hours ±5%

Charging Time (SOC 10%-100%）：5 hours ±5%

Speed According To Acceleration Mode

Beginner mode 15km/h Acceleration

mode 1: 15kmh Acceleration

mode 2: 26km/h Acceleration

mode 3: 36km/h

Run Time At Max Speed：60min

Climbing Angle：16 °

Charger Line Voltage：100V - 240V

Work Environment Temperature：5-40℃

Length x Width x Height：1330x610x789 mm

Wheelbase：952mm

Seat Height：550mm

Minimum Ground Clearance：152mm

Curb Weight：49kg

Maximum Load Capacity：79kg

Steering Head Angle：34°

Colors：Baltic Blue

Frame：Steel tube, double cradle

Rim：Spoked rim

Wheel：2.50-10

Front Suspension：Telescopic φ31mm

Rear Suspension：Center-mounted, preload adjustable

Suspension Travel

Front 72mm

Rear 65mm

Brakes：Disc brakes
